About
Making ice for cocktails and soft drinks, the Manitowoc Ice UDE0080A NEO® ice machine produces dice ice, which is also known as full-cube ice. In 24 hours, it can make 102 pounds and its storage bin holds as much as 31 pounds. Made of polyethylene, the bin liner is strong, seamless, and eases cleaning. Users can access the ice through the sliding door, which moves up and out of the way.
With a narrow, 19.69-inch width, this Manitowoc Ice UDE0080A undercounter ice machine can fit in tight spaces under the counter or stand alone. Its legs are adjustable to accommodate slightly uneven flooring, and for durability and rust resistance, the cabinet is constructed of stainless steel. Internal components are made with AlphaSan® antimicrobial protection to protect the unit between cleanings.
Product Details
- Part of the NEO ice maker series
- 102-lb. maximum daily ice production
- Makes full-cube ice for soft drinks and cocktails
- Dice ice size: 7⁄8 in. x 7⁄8 in. x 7⁄8 in.
- 31-lb. ice storage bin
- Polyethylene bin liner is seamless to ease cleaning
- Bin access door enables convenient ice access by sliding up and out of the way
- AlphaSan antimicrobial agent in key components slows bacteria growth
- Stainless steel cabinet resists rusting and scratching
- Foamed-in-place insulation retains cold air
- Adjustable legs stabilize on uneven floors
- Compact design for under the counter or standalone installation
- Flat, right-angle plug fits in tight spaces
- Replaces the QM-45A
- 2,050 average BTU; 2,500 peak BTU
Product Features
Ideal Operating Conditions
- Surrounding air temperature: 40-110 degrees F
- Incoming water temperature: 33-90 degrees F
- Water pressure: 20-80 PSI
- Clearance: 5 in. on sides, top, and back
Dimensions & Utilities
- 19.69 in. W x 22.34 in. D x 36 in. H
- 5.2 A, 10.7 kW, 1⁄4 HP
- 115 V/60 Hz/1 ph, 6-ft. cord with a NEMA 5-15P plug
Manitowoc Ice UDE0080A Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Manitowoc Ice |
| 24 Hr. Production (lb) | 102 |
| Bin Capacity (lb) | 31 |
| Compressor Type | Air Cooled |
| Depth (in) | 22.34 |
| Drain Type | Gravity |
| Height (in) | 36 |
| Hertz | 60 |
| Ice Type | Full Cube |
| Phase | 1 |
| Product | Undercounter Ice Makers |
| Product Type | Ice Makers & Bins |
| Production Range (lb/day) | 100 - 199 lbs |
| Series | NEO® |
| Special Features | Antimicrobial |
| Suggested Use | Commercial |
| Voltage | 115 |
| Warranty | 3-yr. Parts & Labor, Add'l 2 yrs. Evaporator; Add'l 2 yrs. Parts Compressor |
| Width (in) | 19.69 |
| Weight | 114.00 |
Lease Calculator
EconoLease Calculator
Making ice for cocktails and soft drinks, the Manitowoc Ice UDE0080A NEO® ice machine produces dice ice, which is also known as full-cube ice. In 24 hours, it can make 102 pounds and its storage bin holds as much as 31 pounds. Made of polyethylene, the bin liner is strong, seamless, and eases cleaning. Users can access the ice through the sliding door, which moves up and out of the way.
With a narrow, 19.69-inch width, this Manitowoc Ice UDE0080A undercounter ice machine can fit in tight spaces under the counter or stand alone. Its legs are adjustable to accommodate slightly uneven flooring, and for durability and rust resistance, the cabinet is constructed of stainless steel. Internal components are made with AlphaSan® antimicrobial protection to protect the unit between cleanings.
Product Details
- Part of the NEO ice maker series
- 102-lb. maximum daily ice production
- Makes full-cube ice for soft drinks and cocktails
- Dice ice size: 7⁄8 in. x 7⁄8 in. x 7⁄8 in.
- 31-lb. ice storage bin
- Polyethylene bin liner is seamless to ease cleaning
- Bin access door enables convenient ice access by sliding up and out of the way
- AlphaSan antimicrobial agent in key components slows bacteria growth
- Stainless steel cabinet resists rusting and scratching
- Foamed-in-place insulation retains cold air
- Adjustable legs stabilize on uneven floors
- Compact design for under the counter or standalone installation
- Flat, right-angle plug fits in tight spaces
- Replaces the QM-45A
- 2,050 average BTU; 2,500 peak BTU
Product Features
Ideal Operating Conditions
- Surrounding air temperature: 40-110 degrees F
- Incoming water temperature: 33-90 degrees F
- Water pressure: 20-80 PSI
- Clearance: 5 in. on sides, top, and back
Dimensions & Utilities
- 19.69 in. W x 22.34 in. D x 36 in. H
- 5.2 A, 10.7 kW, 1⁄4 HP
- 115 V/60 Hz/1 ph, 6-ft. cord with a NEMA 5-15P plug
Manitowoc Ice UDE0080A Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Manitowoc Ice |
| 24 Hr. Production (lb) | 102 |
| Bin Capacity (lb) | 31 |
| Compressor Type | Air Cooled |
| Depth (in) | 22.34 |
| Drain Type | Gravity |
| Height (in) | 36 |
| Hertz | 60 |
| Ice Type | Full Cube |
| Phase | 1 |
| Product | Undercounter Ice Makers |
| Product Type | Ice Makers & Bins |
| Production Range (lb/day) | 100 - 199 lbs |
| Series | NEO® |
| Special Features | Antimicrobial |
| Suggested Use | Commercial |
| Voltage | 115 |
| Warranty | 3-yr. Parts & Labor, Add'l 2 yrs. Evaporator; Add'l 2 yrs. Parts Compressor |
| Width (in) | 19.69 |
| Weight | 114.00 |
Lease Calculator
EconoLease Calculator
Manitowoc - UDE0080A-161B 19 11/16" W Full Cube NEO Undercounter Ice Maker - 102 lbs/day, Air Cooled
- Regular price
- $4,335.00
- Sale price
- $4,335.00
- Regular price
-
$5,130.00
Couldn't load pickup availability
